CNC controller comparison
Note, please check documentation to understand signals type and levels
Software License | Included | Included | Included | Included |
Number of axis | 4 | 4 | 6 | 6 |
Step frequency | 125 kHz | 400 kHz | 400 kHz | 125 kHz |
Interface | Ethernet 100Mbit | Ethernet 100Mbit | Ethernet 100Mbit | Ethernet 100Mbit |
Power supply | 24V | 24V | 24V | 24V |
Breakout board | Not required | Avalaible | Avalaible | Not required |
DIN rail mountable | ||||
Expansion interface | Modbus RTU Master | Modbus RTU Master | Modbus RTU Master | |
Wiring | IDC, terminal, RJ45 | IDC / Breakout | IDC / Breakout | Terminal |
Driver signals | Step / Direction | Step / Direction | Step / Direction | Step / Direction |
Driver signal type | Single-ended (TTL) | Single-ended (TTL) | Breakout:
| Single-ended (TTL) |
Inputs | ||||
E-Stop | ||||
Analog | 2 | 2 | 8 | 3 |
Probe | ||||
Drive alarm | ||||
Ext. error | ||||
Start / Run | ||||
Pause / Stop | ||||
Home | 4 | 4 | 6 | 6 |
Spindle pulse | ||||
Handwheel | ||||
VFD Speed OK | ||||
VFD Alarm | ||||
Modbus Warning | ||||
Modbus E-Stop | ||||
Modbus Stop | ||||
Digital In (AUX) | 1 | 1 | 10 | 8 |
E-Stop | ||||
Outputs | ||||
Tool | ||||
Tool direction | ||||
Mist | 1 (Relay) | |||
Flood | 1 (Relay) | |||
Brake | 1 (Relay) | |||
PWM | 8 | 4 | ||
0-10V | 2 | |||
E-Stop | 1 (Relay) | |||
Ext-Error | 1 (Relay) | |||
SysReady | 1 (Relay) | |||
Drive reset | ||||
Digital out (AUX) | 1 (Relay) | 10 | 8 | |
Status | ||||
Micellaneous | ||||
Remarks: | Free included LED status PCB with sticker | |||
Dimensions | 107x163.5mm | 107x100mm | 107x230mm | 107x265mm |
Weight | Bruto Netto | |||
HS-code | 107.163.5mm |
